Performance, emissions & economy
Top speed (mph): 122
0-62 mph (seconds): 10.3
Urban mpg: 33.6
Extra urban mpg: 51.4
Combined mpg: 42.8
CO2 (g/km): 178
|
|
Dimensions & weights
Length (mm): 4391
Height (mm): 1635
Width (mm): 1794
Wheelbase (mm): 2677
Cargo volume (litres): 695
Gross weight (kg): 2240
Kerb weight (kg): 1595
Max. braked trailer weight (kg): 1500
Max. unbraked trailer weight (kg): 750
Fuel tank capacity (litres): 60
|
|
|
|
Engine & transmission
Engine: Four cylinder diesel, in line, transversely mounted in front. Variable geometry turbocharger.
Cubic capacity (cc): 1968
Compression ratio: 18.00:1
Bore x stroke (mm): 81.00 x 95.50
Valve gear: Four valves per cylinder. Double overhead camshafts. Low friction roller cam followers with hydraulic clearance adjustment.
Max. power (bhp): 138 at 4000 rpm
Max. torque (lb.ft): 236 at 1750 rpm
Transmission: Six-speed automatic double clutch DSG (Direct Shift Gearbox). Front wheel drive.
|
|
|
|
Chassis & running gear
Front: Spring struts, telescopic dampers with lower wishbones and anti-roll bar mounted on an aluminium subframe.
Rear: Oil pressure dampers with separate springs. Four-link independent suspension with three lateral control arms.
Steering: Electro-mechanical steering with speed-dependent power assistance.
Brakes: Front: 288mm ventilated discs. Rear: 260mm discs. ABS with Hydraulic Brake Assist, traction control, Electronic Differential Lock and Electronic Stabilisation Programme.
Wheels: 6.5J x 16-inch 'Hockenheim' alloys
Tyres: 205/55 R16
|
|
|
