NEWcars: Nissan Terrano II - 28 August 1999
|
|
No. of cylinders, arrangement: 4, front, in-line Bore x stroke (mm): 89.0 x 96.0 Capacity (cc): 2389 Max. power (bhp): pre-cat. 114 / without pre-cat. 116 (@ 4800rpm) Peak torque (Nm): 191 @ 3200rpm Compression ratio: 8.6:1 Ignition system: Electronic, distributor type Fuel system: Multi-point fuel injection, unleaded petrol |
|
|
Transmission:
Gearbox: 5-Speed manual 1st: 3.592:1 2nd: 2.246:1 3rd: 1.415:1 4th: 1.000:1 5th: 0.821:1 Reverse: 3.657:1 Final drive: 4.625:1 Transfer ratio: high 1.000:1 / low 2.020:1 Consumption - Emissions (l/100km): Urban cycle: 3-door: 15.2 / 5-door: 15.8 Extra urban: 3-door: 10.1/ 5-door: 10.3 Combined: 3-door: 11.9 / 5-door: 12.3 CO2 combined (g/km): 3-door: 282 / 5-door: 292 Performance: Top speed (mph): 99 0-62mph (sec.): 3-door: 13.7 / 5-door: 14.3 Brakes: Ventilated discs front, drums rear, front/rear split circuit, power assisted (electronic 3 channel / 5 sensor ABS with electronic brake distribution) Supplies - Weights: Fuel tank (litres): 3-door: 72 / 5-door: 80 Gross vehicle weight (kg): 2510 / 2580 Max Payload (min/max kg): 870/880 / 740/750 Min Payload (min/max kg): 800/810 / 665/675 Roof load (kg):100 |
Wheels and tyres:
Wheel size:235/70 R16 Chassis and Suspension: Front: Double wishbone with torsion spring and anti-roll bar Rear: Live axle located by five links with coil springs and anti-roll bar. Steering: Power assisted, recirculating ball type. Bodywork: Seats: 5 / 7 Front leg room (mm): 3 door: 1010 / 5 door: 1010 Rear leg room (mm): 3 door: 920 / 5 door: 920 Front head room (mm): 3 door: 1005 / 5 door: 1005 Rear head room (mm): 3 door: 985 / 5 door: 985 Doors: 3/5 Length (mm): 3 door: 4217 / 5 door: 4697 Width (mm): 1755 Overall height (mm): 3 door: 1830 / 5 door: 1850 Track (front / rear) (mm): 1455/1430 Wheelbase (mm): 3 door: 2450 / 5 door: 2650 Luggage capacity (litres): 3 door: 335 / 5 door: 115 Off Road: Approach: (deg) 32.5 Departure: (deg) 35 Gradeability: (deg) 39 Ramp breakover: (deg) 27 Lateral inclination: (deg) 48 Wading depth: (mm) 450 Ground clearance: (mm) 210 |
